Hydrogen generator-HYDROGEN-2L/3L

The Peculiar series ultra-high purity hydrogen generators can continuously and reliably produce hydrogen gas with extremely high p urity, greater than 99.9999%. This eliminates the need for expensive and hazardous high-pressure hydrogen cylinders in the laborato ry, and the interruption of important analytical work due to cylinder replacement will no longer occur. Hydrogen can be generated si mply with deionized water and power supply, with automatic water replenishment, no need for manual water addition, and the cost i s very low. The safety and convenience of the hydrogen generators make them a replacement for the dangerous high-pressure hydrogen cylinders.

MAIN TECHNICAL PARAMETERS

◎ Purity:99.999%-99.9999%

◎ Traffic:2L/min、3L/min

◎ Pressure: Normal pressure 0-0.4Mpa, high pressure 0-1.5Mpa.

◎ Size:400*600*600mm

◎ Net weight: approximately 14Kg

INSTRUMENT FEATURES

◎ Adopt PEM Technology

◎ Without using alkali, directly electrolyzing pure water effectively protects the chromatography column;

◎ Adopting the ion membrane developed by Peculiar of the UK, utilizing Nafion (permeation membrane technolo gy) and Pressure Swing Adsorption dehydration technology (patented);

◎ The instrument uses British Peculiar silicone rubber rings (with low sulfur content) internally, effectively improvin g gas quality and ensuring stable chromatographic baselines.

◎ Both pressure and flow are controlled by an integrated microcomputer.

◎ Automatic water level control, when there is a shortage of water, the machine will automatically shutdown and a  utomatically refill. When the Hydrogen-2L water level drops below 15%, it will automatically refill from an external water tank without the need to stop and add water. This effectively protects the electrolytic cell and extends its serv ice life.

◎ Automatic leak detection;

◎ Compact design, takes up little space;

◎ Environmental filter, easy to install and operate;

◎ Electronic pressure display;

◎ Compatible with gas chromatographs of any model and from any manufacturer.

APPLICATION SCENARIOS

◎GCCentralized gas supply

◎Hydrogen fuel cell

◎CVD and MOCVD fields
