High-purity hydrogen generator-Hydrogen-1000S

The Peculiar hydrogen generator series can continuously and reliably produce hydrogen gas with extremely high purity, greater than 9 9.9999%.This eliminates the need for expensive and hazardous high-pressure hydrogen cylinders in the laboratory.The entire process only requires deionized water and power supply to generate hydrogen,and it can operate continuously for 60 days with a single wate r refill,at a low cost. The safety and ease of use of the hydrogen generator have replaced the dangerous high-pressure hydrogen cylin  ders. Hydrogen is produced on demand and in appropriate quantities, maintaining the volume and safety of hydrogen storage.

MAIN TECHNICAL PARAMETERS

◎ Hydrogen Purity:99.9999%

◎ Hydrogen dew point：-72℃（About 1ppm）

◎ Hydrogen flow rate：300cc/min、500cc/min、1000cc/min

◎ Output pressure：Atmospheric pressure0-0.4Mpa High pressure0-1.5Mpa

◎ Stress stability：< 0.001MPa

◎ Power supply：220V±10%, 50Hz ◎ Power consumption：150W

◎ External dimensions：450×420×180mm 【Hydrogen-500（S）】

◎ Net weight：About 14Kg 【Hydrogen-500（S）】

◎ Water consumption：0.45L/day

INSTRUMENT FEATURES

◎ Adopt PEM Technology

◎ Directly electrolyzing pure water without using alkali effectively protects the chromatography column

◎ Adopting the ion membrane developed by Peculiar in the UK; utilizing Nafion (permeation membrane technolo gy) and pressure swing adsorption dehydration maintenance-free technology (patented), which ensures more ough hydrogen purification to produce hydrogen with a purity of 99.9999%, ensuring the reproducibility of results;

◎ The instrument uses British Peculiar silicone rubber rings (with low sulfur content) internally, effectively improvin g gas quality and ensuring stable GC baselines.

◎ 5-inch LCD color capacitive screen, using a glass panel, displays pressure, flow, and usage status information     a simple and intuitive manner;

◎ Automatic water level control, when there is a shortage of water, it automatically shuts down and refills water hen the Hydrogen-500S water level is below 15%, it automatically refills from an external water tank without ed to stop and add water. This effectively protects the electrolytic cell and extends its service life.

◎ Automatic leak detection;

◎ Compact design, small footprint

◎ Environmental filter, easy to install and operate;

◎ Compatible with GCs from any model or manufacturer.

APPLICATION SCENARIOS

◎ GC and GC-MS as carrier gases

◎ GC-FID/NPD(FTD)/FPD ◎ ICP-MS collision gas

◎ CVD semiconductor applications
